Wireless collaboration display
- Full HD bright and vivid wireless display 3LCD technology and equally high White and Colour Light Output
- Minimal maintenance Years of uninterrupted use before maintenance is required
- Steam and share connectivity Built-in wireless connectivity and Screen Mirroring
- Smart cost savings Lamp life up to 17,000 hours in Eco mode
- Collaborative features iProjection App1, split-screen function, moderator function
Overview
Maximise your presentations with this bright Full HD projector that's capable of producing a large and scalable screen size. The long-lasting lamp provides years of lessons before a replacement lamp is required or the air filter needs attention. It's easy to set up and offers a range of connectivity solutions, so you can quickly access content from multiple devices.
Technology
Projection System
3LCD Technology, RGB liquid crystal shutter
LCD Panel
0,61 inch with C2 Fine
Color Light Output
4.000 Lumen- 2.400 Lumen (economy) In accordance with IDMS15.4
White Light Output
4.000 Lumen - 2.400 Lumen (economy) In accordance with ISO 21118:2020
Resolution
1080p
Resolution Enhancement
Full HD
Aspect Ratio
16:9
On-Screen Pixel Count
2,073,600
Contrast Ratio
16.000 : 1
Light source
Lamp
Lamp
UHE, 230 W, 6.500 h durability, 17.000 h durability (economy mode)
Keystone Correction
Auto vertical: ±30 °, Manual horizontal ±30 °
Colour Video Processing
10 Bits
2D Vertical Refresh Rate
100 Hz - 120 Hz
Colour Reproduction
Upto 1.07 billion colours
Optical
Throw Ratio
1,32 - 2,14:1
Zoom
Manual, Factor:1 - 1,6
Lens
Optical
Screen Size
30 inches - 300 inches
Projection Distance Wide/Tele
1,76 m - 2,86 m ( 60 inch screen ),
Projection Lens F Number
1,51 - 1,99
Projection Lens Focal Length
18,2 mm - 29,2 mm
Projection Lens Focus
Manual
Offset
10 : 1
Connectivity
USB Display Function
2 in 1: Image/ Sound
Interfaces
USB 2.0-A, USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), VGA in (2x), VGA out, HDMI in (2x), Composite in, Jack plug out, Jack plug in (2x), Cinch audio in, Microphone input, Miracast, Wireless LAN IEEE 802.11a/b/g/n/ac
Epson iProjection App
Ad-Hoc / Infrastructure
Network Protocol
PJLink
Advanced Features
Security
Kensington lock, Control panel lock, Security cable hole, Wireless LAN security, Password protection
2D Colour Modes
Dynamic, Cinema, Presentation, sRGB, Blackboard
Other features
AV Mute Slide, Automatic keystone correction, Built-in speaker, CEC compatible, Direct Power on/off, Document Camera Compatible, Easy OSD pre-setting, Horizontal and vertical keystone correction, Network projection, OSD copy function, PC Free, Quick Corner, Split-Screen-Function, Wireless LAN capable, iProjecton set-up by QR code
Video Color Modes
Blackboard, Cinema, Dynamic, Presentation, sRGB
Projector control
via: AMX, Crestron, Control4, Extron
General
Power consumption
286 Watt (Normal On-Mode), 180 Watt (Eco On-Mode), 327 Watt (Normal Peak-mode), 225 Watt (Eco Peak-Mode), 0,3 Watt (Energy saving standby)
Supply Voltage
AC 100 V - 240 V, 50 Hz - 60 Hz
Product dimensions
309 x 282 x 90 mm (Width x Depth x Height)
Product weight
3,1 kg
Noise Level
Normal:37 dB (A) - Economy:28 dB (A)
Supported Temperature
Operation 5° C - 40° C, Storage -10° C - 60° C
Supported Humidity
Operation 20% - 80%, Storage 10% - 90%
If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.
If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.
Included Software
EasyMP Multi PC Projection, Epson Projector Management
Options
Air filter, Ceiling mount, Document camera, External Speaker, Safety wire set, Soft carry case, Suspension adapter, WP System - ELPWP20, Wireless LAN unit, Wireless transmitter - ELPWT01
Loudspeaker
16 Watt
Room Type / Application
Huddle space / Portable, Meeting room / Classroom
Positioning
Ceiling Mounted, Desktop
Colour
White
Other
Warranty
60 months Carry in, Lamp: 60 months or 1.000 h (whichever comes first)
