SR314
Distinctive design. Sonic accuracy.
Legendary performance.
Vocals Come Alive
Like Never Before.
The Earthworks SR314 is designed from the ground up to meet both the expectations and desires of a modern live performance environment.
The Sound
of the SR314
Your true artistic voice, fully realized. Extended flat frequency response and a focus on time coherence set the Earthworks SR314 apart.
Simple, Easy, Brilliant
Capable of handling sound pressure levels of up to 145dB without distortion, the SR314 can handle nearly any vocalist.
A Crystal-Clear Translation
With a tight cardioid polar pattern, the SR314 is imbued with levels of sound isolation not found in other microphones.
Clarity On Stage & In the Studio
A vocal microphones that can seamlessly transition between those two worlds with no compromises.
Specifications
| FREQUENCY RESPONSE |
20Hz – 30kHz |
| POLAR PATTERN |
Cardioid |
| SENSITIVITY |
20mV/Pa (-34dBV/Pa) |
| POWER REQUIREMENTS |
24-48V Phantom, 10mA |
| SIGNAL TO NOISE RATIO |
79dB A-weighted |
| PEAK ACOUSTIC INPUT |
145dB SPL |
| OUTPUT |
XLR (pin 2+) |
| OUTPUT IMPEDANCE |
65Ω balanced (between pins 2 & 3) |
| MIN OUTPUT LOAD |
600Ω between pins 2 & 3 |
| SELF NOISE |
15dB SPL equivalent (A weighted) |
| DIMENSIONS L x D |
181.1mm x 40.6mm (7.13 x 1.60 inches) |
| WEIGHT |
1.5 lb. (.68kg) |
