Lightweight Pantographs-Spigot to Studio Rail – Doughty Engineering
The lightweight pantograph range has been developed to suit smaller luminaires between 3Kg and 15Kg. Luminaires below 3Kg can be used with a ballast weight. Features a Studio Rail 60 carriage at the top and the luminaire is attached via the 16mm spigot at the bottom. Ideal for use in TV and photographic studios. Heavy duty cable clips are fitted to take one power lead plus one signal lead.
Each pantograph is supplied with three springs and a spring adjustment tool and is powder coated black.
Specification
WLL:
15Kg
Finish:
Black
Colour:
Black
Product link:
https://doughty-engineering.co.uk/products/lightweight-pantographs-spigot-to-studio-rail/
