HOPS5 : Point Source

Super-powerful, passive 2-way system with immense output-to-size ratio, and 100° x 100° coverage. If you're looking to kit out a small to medium size venue where you're in need of high fidelity sonics and plenty of kick, HOPS5 is the box for you.

Main Features

• Ultra-compact 2-way coherent point source
• Frequency range: 80 Hz – 20 kHz (-6 dB)
• High power handling of 300 W (AES)
• Double 5” coaxial system
• Symmetrical coverage of 100° x 100°
• Superior sound quality
• Optimised for near-field applications
• High output before feedback
• Available as right or left version
• Ball impact resistant (DIN 18032-3)
• System integration with LINUS DSP amplifiers

Overview

The CODA Audio HOPS5 is an ultra-compact, passive 2-way system with immense output-to-size ratio, and 100° x 100° coverage. If you’re looking to kit out a small to medium size venue where you’re in need of high fidelity sonics and plenty of kick, HOPS5 is the box for you.

These speakers can be used for corporate events or exhibitions, DJ foldback, sound reinforcement for small clubs, or even as stage monitors or front fills at a live show. In the theatre, they work great as under balcony fills.

HOPS5 has a double 5″ coaxial system, high power handling of 300 W, and a symmetrical coverage of 100°. At the heart of HOPS5 are its two super-smart drivers: one 5″/1.75″ neodymium coaxial driver, and an additional 5″  LF driver. The 5″ cone covers the 60 – 1500 Hz frequency range with extremely high efficiency and a silky smooth linear response. What’s particularly clever is the design: three aluminium shorting rings reduce inter-modulation distortion, which minimises induction variation while reducing thermal compression at the same time. In a nutshell, it reduces the distortion massively at longer excursion levels, and in doing so, improves the overall sound quality, providing a smooth and linear response.

The high frequency driver contains an ultra-light 1.75″ annular diaphragm which produces an exceptional transient response with very high efficiency from 1 kHz to 20 kHz. This new transducer was engineered to radiate a single source, coherent 100° wave front for superior dispersion control and pristine and transparent high fidelity sound. Together, they guarantee uniform coverage with perfect time alignment between the components.

HOPS5 is designed to work with dedicated CODA Audio LINUS6.4 amplifier as an integrated solution for DSP control, amplification, network remote control, and diagnostics. This integrated solution guarantees optimal performance as well as protection.
